8.00mm O.D. SHOULDERED FERRULE FOR LB1

Name: 8.00mm O.D. SHOULDERED FERRULE FOR LB1
SKU: RB8M15/1
Price: 1.33 GBP
Availability: InStock

Be the first to review this product

SKU: RB8M15/1

£1.33 £1.11

Availability In Stock

8.00mm O.D. x 14.80mm LONG NOSE. 10.00mm O.D. SHOULDER x 1.60mm WIDE. 6.00mm O.D. GROOVE x 1.00mm WIDE, POSITIONED 3.00mm IN FROM THE NOSE OF FERRULE. BODY O.D. 8.00mm x 25.20mm TOTAL LENGTH. 5.10mm I.D. x 10.00mm DEPTH, SUITABLE FOR 5.00mm CONDUIT. 2.70mm DIAMETER THROUGH HOLE AND SUITABLE FOR WIRE UP TO 1.50mm. ZINC & CLEAR PLATED MILD STEEL.

Details

This ferrule can be fixed to LB1 conduit with a mechanical crimp such as a centre punch, vice compression, or built-for-purpose tooling. At Venhill, we crimp the 8mm O.D. body of this ferrule with a hexagonal jaw press measuring 7.00mm across flats. This provides a superbly strong connection between the ferrule and the conduit.
